Eco Sounder

• Windows XP OS, user-friendly interface

• Full aluminum housing, compact and handy designed forless-than-ideal consumption

• High-speed DSP chip processing technology to ensure reliablewaveform and depth

• Support NMEA-0183 communication to gain orientationinformation

• 12.1-inch color LCD featuring a wide viewing angle and adjustable brightness

eco-sounder-feature1

Measurement
Frequency:	200kHz
Beam Angle:	7°
Depth Resolution:	0.1ft / 0.01m
Accuracy:	±1cm±0.1%D (0.1% of depth value)
Ping Rate: Sound Velocity: Depth Range: Draft: Gain Control: Output data format:	14Hz, Maximum 30Hz 1300-1700m/s, resolution is 1m/s 0.3-300m/900ft 0-9.9m AGC and TVG, depth and gain, a double door tracking SOUTH, SDH-13D, DES025, INN455, ODOM etc
Physical
Environment: Output Power: Power Supply: Dimension: Weight:	-30℃-60℃ non-condensing Up to 300watts 9-15V DC, less than 25w, 110-265V AC (Optional) 35cmH x 29cmL x 14cmW 7.5kg
Hardware part
Embedded OS: I/O interface Display panel layout		CPU frequency 1.6GHz, Internal memory 1G, Storage capacity 4G CF card (support extended storage) 2 x USB, 2 x RS232, 1VGA interface 12.1-inch touch screen, power on/off, Interface protection, Keyboard, Mouse
